Call Center Analytics: Part 1 -Building a Scalable Infrastructure on AWS

Call centers are a major part of customer service in the modern economy. However, maintaining an efficient and scalable call center poses significant technological challenges. Amazon Web Services offers a suite of services that can be leveraged to build a flexible data analytics infrastructure for a call center. This article explores how to utilize AWS to handle call recordings, transcriptions, sentiment analysis, and data storage securely and scalable.

Check out the code repo here.

Deep Dive into the Architecture

A well-designed analytics center on AWS uses a collection of interconnected services, each serving a unique purpose. At the heart of our system, Amazon S3 stores call recordings, while AWS Lambda functions initiate processing tasks like transcription. It will also host our front-end website that we will discuss later

Setting Up S3 for Call Recording Storage

S3 buckets are the starting point of our call center workflow. They provide a durable, highly available, and extremely cost-effective storage solution (pennies per GB/month.)

Enforcing encryption in transit and at rest is crucial for security, especially when a customer's PII is involved. S3's encryption features, such as Server-Side Encryption with Amazon S3-Managed Keys (SSE-S3) or AWS Key Management Service (AWS KMS), can achieve this.

Lambda for Processing

AWS Lambda is an event-driven, serverless computing service that runs our code in response to certain triggers, such as the arrival of a new call recording in our S3 bucket.

Lambda functions can be written in various languages. Below is an example of a Lambda function in Python that initiates the transcription process using Amazon Transcribe.

def lambda_handler(event, context):

    DYNAMO_TABLE = os.environ['DYNAMO_TABLE']

    TRANSCRIBE_S3_BUCKET = os.environ['TRANSCRIBE_S3_BUCKET']



    for record in event['Records']:

        source_bucket_name = record['s3']['bucket']['name']

        key = unquote_plus(record['s3']['object']['key'])

        file_uri = f's3://{source_bucket_name}/{key}'



        transcribe_job_name = f"Transcription-{datetime.now().strftime('%Y%m%dT%H%M%S')}"

        transcribe_client.start_transcription_job(TranscriptionJobName=transcribe_job_name,

            Media={'MediaFileUri': file_uri}, MediaFormat='mp3', LanguageCode='en-US',

            OutputBucketName=TRANSCRIBE_S3_BUCKET, Settings={'ShowSpeakerLabels': True, 'MaxSpeakerLabels': 2})



        while True:

            status = transcribe_client.get_transcription_job(TranscriptionJobName=transcribe_job_name)

            if status['TranscriptionJob']['TranscriptionJobStatus'] in ['COMPLETED', 'FAILED']:

                break



        if status['TranscriptionJob']['TranscriptionJobStatus'] == 'COMPLETED':

            transcript_key = f"{transcribe_job_name}.json"

            transcript_response = s3_client.get_object(Bucket=TRANSCRIBE_S3_BUCKET, Key=transcript_key)

            transcript = json.loads(transcript_response['Body'].read().decode('utf-8'))

            full_text = process_transcript(transcript['results'], transcript['results']['speaker_labels'])



            summary_response = invoke_bedrock_model(full_text)

            summary = summary_response.get('completion', '')



            logger.info(summary)



            thirds = [full_text[i:i + len(full_text) // 3] for i in range(0, len(full_text), len(full_text) // 3)]

            sentiments = [comprehend_client.detect_sentiment(Text=part, LanguageCode='en')['Sentiment'] for part in

                          thirds]



            table = dynamodb.Table(DYNAMO_TABLE)

            table.put_item(Item={'UniqueId': key.split('.')[0], 'Date': datetime.now().strftime('%Y-%m-%d-%H-%M-%S'),

                'TranscriptionFull': full_text, 'Sentiment0': sentiments[0], 'Sentiment1': sentiments[1],

                'Sentiment2': sentiments[2], 'Summary': summary.strip()})

            return {'statusCode': 201, 'body': json.dumps('Success')}

        else:

            return {'statusCode': 500, 'body': json.dumps('Transcription job failed')}

Security Considerations

Every operation is given the least privilege from the front end to the backend.

Utilizing AWS for a call center infrastructure offers significant benefits, such as scalability, reliability, and a pay-as-you-go pricing model. By following best security practices and leveraging serverless architectures, we can build a system that not only scales automatically to meet demand but also maintains the security and privacy of the data it handles.

As I show you how this was built so you can build a scalable analytics platform for a call center on AWS, remember the importance of each component and how they interconnect to provide a seamless customer service experience.
